VHF Headset Wireless Microphone System - Black

Incredibly affordable VHF Headset Wireless Microphone System delivers crisp, natural sound!

Availability: Available For Order

$229.00
OR
VHF Headset Wireless Microphone System - Black

More Views

Details

Don't let the low price of this wireless microphone system fool you - it's loaded with features - and a premium black headset microphone!

Advanced dipole antenna design delivers extended operating range, which improves operation by providing a ground element in addition to the usual signal element. This VHF wireless microphone system also features a durable non-diversity, single-channel receiver, Power, RF, and AF Peak indicators, volume control, and a +" output jack. Get up to 20 hours of battery life from a 9 volt battery(sold separately).

Included headset microphone features a comfortable, adjustable earpiece that can be worn on either ear. Its small profile virtually disappears so people can focus on your words - not your microphone. Buy this complete wireless headset microphone system today and save!

Additional Information

SKU SYSK24B
Manufacturer Kingdom
MPN SYSK24B
Technical Specifications "


Operating Frequency
VHF high band, 169 MHz to 172 MHz

Number of Channels Fixed channel

Frequency Stability ¦0.005%

Modulation Mode FM

Maximum Deviation ¦15 kHz

Operating Range 200' typical

Operating Temperature Range 40¦ F (4¦ C) to 110¦ F (43¦ C)

Frequency Response 80 Hz to 13 kHz

 RECEIVER SPECIFICATIONS


Receiving System Non-diversity, single-channel, dual antenna system

Image Rejection 50 dB minimum

Signal-to-noise Ratio 80 dB at 10 kHz deviation (IEC-weighted), maximum modulation 15 kHz

Total Harmonic Distortion <=1% (10 kHz deviation at 1 kHz)

Sensitivity 20 dB¦V for 60 dB S/N (IEC-weighted)

Audio Output 350 mV (1 kHz modulation, 10 kHz deviation, 100 k ohm load)

Output Connector 1/4"" TS (""mono"") phone jack

Power Supply 100-240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply

Dimensions 7.48"" (190.0 mm) W x
1.65"" (42.0 mm) H x
5.12"" (130.0 mm) D

Net Weight 11.0 oz (311 g)

Accessory Included Power supply

 BODY-PACK TRANSMITTER SPECIFICATIONS



RF Power Output
10 mW High position, 2 mW Low position, typical

Spurious Emissions
Under federal regulations

Dynamic Range
>=90 dB, A-weighted

Input Connections
High impedance, low impedance, bias

Battery
9V (NEDA type 1604) alkaline, not included

Current Consumption
30 mA typical

Battery Life
Approximately 15 hours in High position;
Approximately 20 hours in Low position
(depending on battery type and use pattern)

Dimensions
2.56"" (65.0 mm) W x
4.33"" (110.0 mm) H x
1.00"" (25.4 mm) D

Net Weight
2.8 oz (78 g) (without battery)




MICROPHONE SPECIFICATIONS

Back Electret Condenser
Omni-directional
Frequency response: 20Hz - 20KHz
Sensitivity: -45db¦3db
Includes windscreen & carrying/storage case



"
Dimensions N/A
Features No
